Detailed features
Harken T2 Block Carbo Pulley:
This Harken model has no metal rivets or shackles, the heavy-duty Carbo T2 tackle block is made of composite materials. The version or double can be attached by knotted or spliced transfers to almost any element. These blocks can be used to adjust cars, mainsheet or vang sheets, to create stepped hoists or bridle systems and any other system that requires lightweight blocks.
Detailed characteristics of the pulley
- Dyneema rope included
| Diameter | 4 mm | 4.8 mm | 6.4 mm | 7.9 mm | 9.5 mm | 12.7 mm |
| Height | 22 mm | 27 mm | 39 mm | 48 mm | 53 mm | 64 mm |
| Width | 10 mm | 10 mm | 14 mm | 16 mm | 16 mm | 19 mm |
| UDL | 800 kg | 1400 kg | 2300 kg | 3600 kg | 5800 kg | 7700 kg |
| PL | 600 kg | 800 kg | 1400 kg | 2700 kg | 4500 kg | 7500 kg |
| Weight | 5 g | 15 g | 30 g | 65 g | 90 g | 165 g |
- Version 18 single / double
- Sheave diameter: 18 mm / 18 mm
- Length: 28 mm / 28 mm
- Weight: 7g / 17g
- Maximum string diameter: 5 mm / 5 mm
- Maximum working load: 125 kg / 204 kg
- Breaking load: 450 kg / 680 kg
- Version 29 single / double
- Sheave diameter: 29 mm / 29 mm
- Length: 43 mm / 43 mm
- Weight: 12g / 24g
- Maximum string diameter: 8 mm / 8 mm
- Maximum working load: 150 kg / 272 kg
- Breaking load: 454 kg / 861 kg
- Version 40 single / double
- Sheave diameter: 40 mm / 40 mm
- Length: 57 mm / 57 mm
- Weight: 25g / 48g
- Maximum string diameter: 10 mm / 10 mm
- Maximum working load: 220 kg / 317 kg
- Breaking load: 544 kg / 952 kg
